If you’re an Arctic Cat F800 owner or a snowmobile enthusiast, you understand how crucial the drive belt is to your sled’s performance. It’s what transfers the engine’s power to the track, keeping your machine running smoothly through snow-covered trails. Over time, the belt can wear out or get damaged, making regular inspections and occasional replacements essential.
This blog will provide a comprehensive guide on how to remove the belt on a 2012 Arctic Cat F800 snowmobile. We’ll walk through the tools you’ll need, the step-by-step process, and the best practices for inspection and maintenance. You’ll also find troubleshooting tips for common belt problems to ensure your snowmobile stays in top shape.
Meet the Arctic Cat F800 Belt System
The Arctic Cat F800 is powered by an efficient Continuously Variable Transmission (CVT) system. It uses a drive belt to transfer energy from the primary drive clutch to the secondary driven clutch. The belt system plays a significant role in maintaining speed, handling, and overall performance.
However, like any component, the drive belt is subject to wear and tear. Whether you’re experiencing belt slippage, noticing wear lines, or planning routine maintenance, knowing how to remove the belt is a skill every F800 owner should have.
Tools You’ll Need for Belt Removal
Before you begin, it’s essential to have the right tools on hand. Here’s a list of everything you’ll need:
- A 13mm wrench or socket for accessing panels
- A belt removal tool (usually comes with your snowmobile toolkit)
- Clean cloth for wiping debris
- Gloves for protection
- Flashlight to inspect hard-to-see areas
- An optional torque wrench (for reinstallation if aligned with a specific torque spec)
Having these tools ready will ensure a smooth and hassle-free process.
Step-by-Step Guide to Removing the Belt
Removing the belt from your Arctic Cat F800 is a straightforward process when done correctly. Follow these steps:
Step 1: Locate the Drive Clutch Cover
Start by finding the clutch cover on the side of your snowmobile. Use the 13mm wrench to remove the bolts securing the cover in place. Be sure to keep the bolts somewhere safe, as you’ll need them for reinstallation.
Step 2: Inspect the Clutch Components
Before removing the belt, examine the clutches for any signs of wear or dirt. This is an excellent opportunity to clean off debris and ensure your clutches are in good condition.
Step 3: Open the Secondary Clutch
Insert the belt removal tool into the threaded hole on the secondary clutch (this tool is designed to spread the clutch sheaves apart). Turn the tool until you see the belt loosen. If you don’t have a belt removal tool, gently rotate the secondary clutch while pushing inward to create slack.
Step 4: Remove the Belt
With the belt now loose, carefully slip it off the secondary clutch first. Then, slide it off the primary clutch. Be gentle to avoid bending or damaging the belt during removal.
Step 5: Inspect and Clean the Area
Once the belt is removed, inspect it for signs of excessive wear, cracks, or fraying. Clean the area around the clutches with a cloth to prevent debris from getting into the system during reinstallation.
Inspection and Maintenance Tips
Taking steps to inspect and maintain your belt can save you from unexpected breakdowns and costly repairs. Here’s what you should look out for:
- Wear Indicators: Most drive belts have wear lines to show when they need replacing. If the wear line has disappeared, it’s time for a new belt.
- Cracks or Fraying: Check for visible damage to the belt material. Even minor cracks can grow under stress.
- Belt Width: Use calipers to measure the width of the belt. Compare it to the specifications in your Arctic Cat owner’s manual to see if it’s within acceptable limits.
- Cleaning: Keep the belt free of dirt, grease, and oil, as these can cause slippage and reduce performance.
When reapplying or replacing the belt, ensure proper alignment and tension to maintain efficient operation.
Troubleshooting Common Belt Issues
While the CVT belt system on an Arctic Cat F800 is robust, issues can arise. Here are a few common problems and their potential solutions:
Problem 1: Belt Slippage
- Cause: The belt may be worn or improperly tensioned.
- Solution: Inspect the belt for wear; replace it if necessary. Check clutch alignment and adjust tension if needed.
Problem 2: High Belt Temperature
- Cause: Overheating can result from aggressive riding or improper clutch calibration.
- Solution: Allow the belt to cool down. Check for signs of glazing, which may indicate prolonged overheating.
Problem 3: Poor Acceleration
- Cause: A loose or damaged belt can impact performance.
- Solution: Inspect the belt for signs of stretching or fraying and replace it if needed.
Problem 4: Difficulty Shifting Gears
- Cause: Incorrect belt size or slack tension.
- Solution: Ensure you’re using the right belt type for your Arctic Cat F800 and adjust tension accordingly.
Enjoy Smoother Rides with a Well-Maintained Belt
Maintaining your Arctic Cat F800’s drive belt is the key to ensuring peak performance and extending the life of your snowmobile. By following this guide, you’ll not only gain confidence in removing and inspecting the belt but also prevent common issues before they arise. Whether you’re gliding over powdery snow or navigating icy tracks, a well-maintained belt will make every ride seamless and enjoyable.
